Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories

Brand Name : BRANDO or OEM

Model Number : BF001

Certification : CE, ISO

Place of Origin : Ningbo, China

MOQ : 1 pcs

Price : negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10000000PCS PER MONTH

Delivery Time : 7 working days after payment

Packaging Details : PVC bag, inner box, carton, pallet

Part Name : Fast fitting inner claw

Material : Acetal, Polypropylene, Brass

Size : 1/8" 1/4" 3/8" 1/2"

Type : Quick connecting, Push in type

Application : Water purification, Beverage, Pneumatic

OEM : Yes

ODM : Yes

Contact Now

Food Grade Plastic Fast Fitting Inner Claw Used on Water Treatment Reverse Osmosis System


Types of Claw for your option:

Fast fitting inner claw, inner hand
Part No. Tube Size
BF001-A 1/4"
BF001-B 3/8"
BF001-C 1/2"

Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories

Specification of plastic claw for fast fitting:

1--Material: FDA & NSF certified POM plastic
2--Application :
Our quick fittings and connectors are widely used in water, beverage and food applications,
such as RO water filtration system, water treatment system, coffee maker, beverage machine,
refrigerator, vending machine, and so on.
3-- Leakage Proof Design: Have been proved in markets for years.
4-- Light weight, and easy to install.
5-- Color: white or grey body with blue locking clip.

Application example of fast fitting inner claw, inner hand:

Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories

Material Standards:

Material Options Fitting Color O-ring
Acetal Grey, Black, White NBR/EPDM
Polypropylene White NBR/EPDM
Brass Brass, or chromed NBR/EPDM

Fitting Working Pressure and Temperature:

Small Size Large Size
5/32" 3/16" 1/4" 5/16" 3/8" 1/2" 5/8" 7/8" 28mm
4mm 5mm 6mm 8mm 10mm 12mm 15mm 16mm 18mm 22mm 28mm

1℃

34℉

16bar

230psi

11bar

170psi

11bar

170psi

20℃

68℉

16bar

230psi

11bar

170psi

11bar

170psi

65℃

150℉

10bar

150psi

7bar

100psi

7bar

100psi

Outer Diameter Tolerance Limit of Tubing Used with Fittings:

Size Tolerance
small size 5/32", 4mm +-0.004" (+-0.1mm)
small size 3/16", 5mm +-0.004" (+-0.1mm)
small size 1/4", 6mm +-0.004" (+-0.1mm)
small size 5/16", 8mm +-0.004" (+-0.1mm)
small size 3/8", 10mm +-0.004" (+-0.1mm)
small size 1/2", 12mm +-0.004" (+-0.1mm)
large size 5/8", 15(16)mm +-0.004" (+-0.1mm)
large size 7/8", 18(22)mm +-0.004" (+-0.1mm)
large size 28mm +-0.004" (+-0.1mm)

Maximum Permissible Torque:

1/8", 1/4" 3/8", 1/2" 3/4"
Plastic Maximum Torque Nm 1.5 3.0 4.0
Steel Maximum Torque Nm 7.0-9.0 12.0-14.0 22.0-24.0 28.0-30.0 40.0

We aslo have many types quick fitting, push-in tube fitting, weclome your any question, we will response at once

Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories
