2S Series 2'' Inch 2S500-50 Uni-D Type Stainless Steel Solenoid Valve

Brand Name : Brando

Model Number : 2S500-50

Certification : CE

Place of Origin : China

MOQ : 1 pc

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100000 pcs per month

Delivery Time : 7 working days

Packaging Details : inner boxes,cartons,pallets

Valve Series : 2S Series

Ref. Number : UNI-D Type SUW-50

Voltage : AC110V AV220V DC24V

Action : Pilot Diaphragm

Port Size : 2'' Inch

Media : Water Air Gas

Fluid Viscossity : Below 20 CST

Power : Solenoid

Body Material : Stainless Steel

Diaphragm Material : NBR, FKM and EPDM

Contact Now

2S Series 2'' Inch 2S500-50 Uni-D Type Stainless Steel Solenoid Valve

Technical Data of 2W & 2S Solenoid Valve:

2W Series
2W025-08
2W040-10
2W160-15
2W200-20
2W250-25
2W350-35
2W400-40
2W500-50
2S Series
2S025-08
2S040-10
2S160-15
2S200-20
2S250-25
2S350-35
2S400-40
2S500-50
Orifice Size
2.5
4
15
20
25
35
40
50
Port Size
1/4''
3/8''
1/2''
3/4''
1''
1-1/4''
1-1/2''
2''
Medium
Water, Air, Gas, Oil
Action
Direct Acting
Semi-Direct Diaphragm Operated
Function
2 Way, Normally Closed
Fluid Viscosity
20 CST below
Pressure
Range
0 to 1.0 Mpa
Temp. Range
-5 to +85℃

Main dimension of 2W & 2S Series Solenoid Valves:
2S Series 2'' Inch 2S500-50 Uni-D Type Stainless Steel Solenoid Valve

2S Series
2W Series
A
B
C
D
E
2S025-06
2W025-06
64.5
30
75
43
1/8''
2S025-08
2W025-08
64.5
30
75
43
1/4''
2S040-10
2W040-10
70.6
32
82.4
53
3/8''
2S160-10
2W160-10
101.5
57
117
69
3/8''
2S160-15
2W160-15
101.5
57
117
69
1/2''
2S200-20
2W200-20
107
57
123.5
73
3/4''
2S250-25
2W250-25
111.5
73.5
134.5
99
1''
2S350-35
2W350-35
142
95
172
123
1-1/4''
2S400-40
2W400-40
142
95
172
123
1-1/2''
2S500-50
2W500-50
172
123
209
168
2''

Security

Generally, the solenoid valve is not waterproof. When the conditions are not allowed, please choose waterproof type, the factory can be customized.
The highest nominal pressure of the solenoid valve must exceed the maximum pressure in the pipeline, otherwise the service life will be shortened or other unexpected conditions will occur.
Corrosive liquids should be selected from all stainless steel type, and strong corrosive fluids should be selected from plastic king (SLF) solenoid valves.
Explosive environments must use the corresponding explosion-proof products.

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
