Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch
Pneumatic Actuated Ball Valve offered by BRANO helps to automatically control the fluid flow using BRANO pneumatic rotary actuator. BRANDO makes high quality Investment casted ball valves with ISO 5211 mounting pad are very much suitable for direct mounting of Pneumatic Actuator on Ball Valves. The Actuator used is of Single acting and Double acting depending upon the application. Single acting actuator is used where power fails causes valve to close. On the other hand, Double acting actuator is used where differential pressure on both the supply ports which leads to open and close the valve.
Main components of ball valve include Body, Ball, Seat (PTFE, RPTFE, CFT, Viton etc), Stem, Gland, and Lever. Ball valve is a quarter turn valve which is operated by rotating the ball at its axis to open and close the fluid flow. Ball Valve provides bubble tight shutoff as it uses Soft seat for sealing. Also, the Ball Valve is highly resistant to contaminated media as compared to other valves. BRANO offers Ball valve in 2-Piece and 3- Piece design available in Screwed , Socket and flanged end as per international standards.
Technical Data of Pneumatic Ball Valve:
| | |
Air Pressure: 0.4 to 0.8 MPa | Electric Actuator Power: 380VAC, 220VAC, 110VAC (50/60Hz), 24VDC Electric Actuator Input: 4-20mA. DC |
Control Medium: Neutral Gas, Air |
Ambient Temperature: -20 to +60℃ |
Medium Temperature: -20 to +180℃ UPVC Ball Valve: -10 to +45℃ CPVC Ball Valve: -15 to +90℃ |
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃) |
Manufacturing Standard: GB, ISO, ANSI, BS, DIN |
Main Dimension of Pneumatic Ball Valve:
