Brand Name : BRANDO
Model Number : G8B
Certification : CE, ISO
Place of Origin : Ningbo, China
MOQ : 2pcs
Price : Negotiation
Payment Terms : T/T, PayPal, Western Union
Supply Ability : 10000pcs per month
Delivery Time : 7 working days
Packaging Details : Box, Carton, Pallet
Product Name : Solenoid Valve
Port Size : 1/4'', 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
Orifice Size : 14mm, 25mm, 40mm
Function : 2 Way Normally Closed
Operation : Piston Pilot Operated
Body Material : Brass
Seal Material : PTFE
Working Temperature : -20 to +180℃
Working Media : Steam, Hot Water, High Temperature Gas and Liquids, etc
Working Pressure : 0.5 to 16 bar
Voltage : 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
180℃ 16 bar Steam Hot Water Brass Solenoid Valve 1/4'' to 2'' 220V 110V 24V
This is a solenoid valve for steam, hot water, high temperature gas and liquids, etc, 1/4'' to 2'' female threaded port size, 14mm to 40mm orifice size, 2 way normally closed, piston pilot operated, 0.5 to 16 bar working pressure, PTFE seal, -20 to +180℃ working temperature, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc.
Technical Data:
Model No | Port Size | Orifice Size | Kv | Working Pressure | Body | Seal | Function | Voltage |
G8B14B02 | 1/4'' | 14mm | 1.5 | 0.5 to 16 bar | Brass | PTFE | 2 Way NC | 12VDC 24VDC 24VAC 110VAC 220VAC |
G8B14B03 | 3/8'' | 14mm | 3 | |||||
G8B14B04 | 1/2'' | 14mm | 3.8 | |||||
G8B14B06 | 3/4'' | 14mm | 4.2 | |||||
G8B25B06 | 3/4'' | 25mm | 9 | |||||
G8B25B25 | 1'' | 25mm | 11 | |||||
G8B40B32 | 1-1/4'' | 40mm | 23 | |||||
G8B40B40 | 1-1/2'' | 40mm | 24 | |||||
G8B40B50 | 2'' | 40mm | 28 |
Main Dimension:
Model No | Port | L | K | H |
G8B14B02 | 1/4'' | 65 | 41 | 125 |
G8B14B03 | 3/8'' | 65 | 41 | 125 |
G8B14B04 | 1/2'' | 65 | 41 | 125 |
G8B14B06 | 3/4'' | 69 | 41 | 131 |
G8B25B06 | 3/4'' | 92 | 60 | 147 |
G8B25B25 | 1'' | 92 | 60 | 147 |
G8B40B32 | 1-1/4'' | 125 | 92 | 173 |
G8B40B40 | 1-1/2'' | 125 | 92 | 173 |
G8B40B50 | 2'' | 129 | 92 | 186 |
Our Production:
FAQ:
Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of
applications.
Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.
Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
Similar Valves:
![]() | ![]() | ![]() | ![]() |
Max 185℃, 15 bar | Max 300℃, 16 bar | Max 225℃, 25 bar | Max 300℃, 16 bar |
